A Scan / B Scan

• Built-in 16GB D disk can store data, images and reports
• USB Support U disk, software upgrade and one-key storage
• DICOM 3.0 Network port makes data transmission easily


• The system comes with simple, practical, easy-to-work software to print and manage di
• Report-print, screen copy, IOL report, case reports with images

Scan Modes A Scan Application Hospital Brand Matronix IOL Formula Hoffer Q, SRK 2, SRK T Accuracy -+0.1 mm Dimension 200*168*165(mm,L*W*H) power 45 VA Examination modes Normal,Aphakic,pseudophakic and dense cataract Measurement mode immersion and contact,auto and Gain Adjustbale 0-120 db IOL formulas SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS Light Red-Light A-Scan probe 10MHz Measurement range 0.23-1.20 mm Measurements ACD,Lens,Vitreous and AXL Measurements Range 15-35 mm (vel 1640 m/s) Power requirement AC 100-240V 50-60 Hz Rate power - 45 VA Probe Frequency 10 MHz Probe frequency Pachy Meter 20 Mhz Resolution 0.01 mm   Show actual value and deviation at the same timeSensitive, convenient, accurate and fast measurementThe Probe service life is long, better cost performance Point and surface point measurementCabinet and delicate foot switch, convenient operationCalculate the calibration value of intraocular pressure (after achieving accurate intraocularpressure)Ultrasonic velocity and offset is adjustable compare measuring results with other equipmenteasily.5.7’ color LCD touch screen, and user information can be easily input, more convenient andquick.A-Scan Bio meter measurement integration of AL measurement and IOL calculation . reading average and standard deviation improve reading accuracy and liability 4 automatic measuring mode: normal. Cataract ,aphakic and special. IOL Calculation:- SRK-II, SRK-T, BINKHORST, HOLLADAY, HOFFER-Q, HAIGIS, any of two groups can control display. Calculate IOL,DEM,DAM, REEF, etc. And long term save 100 groups of measurement results of A scan.Specifications AddedEdit Accuracy: -+0.1 mm Application: Hospital Brand: Matronix Dimension: 200*168*165(mm,L*W*H) Examination modes: Normal, Aphakic, pseudophakic and dense cataract Measurement mode immersion and contact , auto and Gain Adjustable: 0-120 dB Gain Adjustbale: 0-120 db IOL formulas: SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS Light: Red-Light A-Scan probe 10MHz Measurement range: 0.23-1.20 mm Measurements: ACD,Lens,Vitreous and AXL Measurements Range: 15-35 mm (vel 1640 m/s) Power requirement: AC 100-240V 50-60 Hz Rate power - 45 VA Probe Frequency: 10 MHz Probe frequency Pachy Meter: 20 Mhz Resolution: 0.01 mm power: 45 VA

Scan Modes A Scan Application Hospital Brand Matronix IOL Formula Hoffer Q, SRK 2, SRK T Accuracy -+0.1 mm Dimension 200*168*165(mm,L*W*H) power 45 VA Examination modes Normal,Aphakic,pseudophakic and dense cataract Measurement mode immersion and contact,auto and Gain Adjustbale 0-120 db IOL formulas SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS Light Red-Light A-Scan probe 10MHz Measurement range 0.23-1.20 mm Measurements ACD,Lens,Vitreous and AXL Measurements Range 15-35 mm (vel 1640 m/s) Power requirement AC 100-240V 50-60 Hz Rate power - 45 VA Probe Frequency 10 MHz Probe frequency Pachy Meter 20 Mhz Resolution 0.01 mm   Show actual value and deviation at the same timeSensitive, convenient, accurate and fast measurementThe Probe service life is long, better cost performance Point and surface point measurementCabinet and delicate foot switch, convenient operationCalculate the calibration value of intraocular pressure (after achieving accurate intraocularpressure)Ultrasonic velocity and offset is adjustable compare measuring results with other equipmenteasily.5.7’ color LCD touch screen, and user information can be easily input, more convenient andquick.A-Scan Bio meter measurement integration of AL measurement and IOL calculation . reading average and standard deviation improve reading accuracy and liability 4 automatic measuring mode: normal. Cataract ,aphakic and special. IOL Calculation:- SRK-II, SRK-T, BINKHORST, HOLLADAY, HOFFER-Q, HAIGIS, any of two groups can control display. Calculate IOL,DEM,DAM, REEF, etc. And long term save 100 groups of measurement results of A scan.Specifications AddedEdit Accuracy: -+0.1 mm Application: Hospital Brand: Matronix Dimension: 200*168*165(mm,L*W*H) Examination modes: Normal, Aphakic, pseudophakic and dense cataract Measurement mode immersion and contact , auto and Gain Adjustable: 0-120 dB Gain Adjustbale: 0-120 db IOL formulas: SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS Light: Red-Light A-Scan probe 10MHz Measurement range: 0.23-1.20 mm Measurements: ACD,Lens,Vitreous and AXL Measurements Range: 15-35 mm (vel 1640 m/s) Power requirement: AC 100-240V 50-60 Hz Rate power - 45 VA Probe Frequency: 10 MHz Probe frequency Pachy Meter: 20 Mhz Resolution: 0.01 mm power: 45 VA

Product Description

For over 30 years Accutome has built a reputation for high quality, reliable and reasonably priced ophthalmic diagnostic equipment. The addition of the 4Sight is no exception. Designed with eye care professionals in mind, the 4Sight provides a single solution for ophthalmic diagnostics by combining an A-Scan, B-Scan, UBM, and Pachymeter in one, easy to use platform. We realize the demands on today’s busy clinics and designed the 4Sight to meet those needs by delivering a high-value product that is accurate and efficient.

• Turbid refractive media: ultrasound scanning is the best option to show the intra-ocular diseases.
• Somatometry of the eye
• Diagnosis before and after vitrectomy to confirm the range and extent of disease.
• Diagnosis and location of ocular trauma and intra­ocular foreign body.
• Intra-ocular tumor
• Diagnosis of exophthalmos
• Ocular and orbit hemodynamics
• Intrusive ultrasound to take out non-magnetic intra­ocular foreign body; tumor puncture under ultrasound guidance.

A- Scan:

• Display: B, B/B, 4B , B/A, A five-point measure, A single point measure
• Measure Range: A Five-point: 0~36mm; A single-point: 0~72mm
• Measure: ACD, Lens, Vitreous, CCT, AXL(immersion mode)
• Eye type: Normal/Aphakic/ Dense Catract/ Manual
• Measure mode: Immersion and contact, manual and auto measurement
• Calculation : std. Deviation, Average, auto average measurement of eight
• groups , result correction,
• Measurement method: A five-point measurement, A single-point measurement IOL formulas: SRK-II, SRK-T, BINKHORST, HOLLADAY, HOFFER-Q, HAIGIS,
• Display of random two formulas, calculation of degree of IOL, DEM of
• emmetropization of IOL, DAM of IOL, REEF after surgery,
• 100 groups of A scan results storage

A single point measurement:

• Magnification: x1.0, x2.0, x4.0
• Depth display: 0~36mm
• Delayed depth: 0~36mm

B-Scan:

• Scan mode : sector scanning, stepping motor with high precision
• Comparison of two or four images
• Depth selection: 24mm, 31 mm, 38mm, 42mm, 45mm,
• 49mm, 52mm, 56mm total 8 grades
• Compression Curve:8
• Post-processing:8
• Postponed depth range: 25-32mm Local zoom Up/down, L/R image tuning Color option:8
• Image storage :more than 10,000 images
• Cine loop:256 frames, measurement available
• Annotation: input character and arrow, Chinese/English available
• Disk management
• Measurement: distance, circumference, volume, angle, histogram, sectional view, etc.
• Report print: screen copy, IOL report, medical record with image etc. Language :Chinese/English
• USB2.0 to support U disk(file manipulation, software upgrade, one -key storage, etc)
• Internal D disk(4G) for data, image , report, movie clip

ccutome’s PachPen and PachPen Vet handheld pachymeters are the perfect combination of accuracy, portability and comfort. The superior ergonomic design fits comfortably in any hand, which is a major improvement from other handheld models.The PachPen handheld pachymeter is also equipped with Accutome’s Digital Signal Analysis which will eliminate non perpendicular measurements on the cornea.

- 65 MHz sampling probe ensures precise measurements.

- IOP correction calculation converts IOP measurements in seconds.

- Superior ergonomic design fits comfortably in any hand.

- Versatility helps to save time and ease you practice demands.

- Gentle touch 2.5 mm diameter probe tip ensures patient comfort.

- Long-lasting lithium battery will last approximately 15,000 readings.

- The PachPen weighs only 3.0 ounces (85 g.)

Measurement Range 0.23 - 1.3 mm Brand Matronix Accuracy (+/- 5)% Resolution (+/-)2 Micron Probe Frequency 10 Mhz Gain Adjustable 0 - 120 dB Measurements Range 15-35 mm (vel 16) Measurements ACD,Lens,Vitreous,and AXL Examination Modes Normal,Aphakic,Pseudophakic and dence cataract Measurement Mode Immersion and contact,auto and manual IOL Formulas SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS Dimension 200*168*165 mm Power Requirement AC 100-240V 50-60Hz Rate power Product Specification Probe Frequency 20 Mhz Measurement range 0.23~1.3mm Power Requirement AC 100-240V 50-60Hz| Rate power: Dimension 200*168*165 mm, (L*W*H) Product DescriptionBiometer   Main unit 10.0MHz A probe. Lithium battery   Adapter Battery charger   Gage block for calibration Footswitch   Footswitch   Pachymeter Main unit 20.0MHz angled probe Lithium battery   Adapter Battery charger   Gage block for calibration Footswitch   Footswitch   Biometer Probe Frequency 10 Mhz Resolution 0.01mm Accuracy ±0.02mm Gain adjustable 0 - 120dB Measurement range 15~35 mm (vel 1640m/s) Measurements ACD, Lens, Vitreous, and AXL Examination modes Normal, Aphakic, pseudophakic and dense cataract Measurement mode Immersion and contact , auto and manual IOL formulas SRK-II, SRK-T, BINKHORST, HOLLADAY, HOFFER-Q, HAIGIS Power requirement AC 100-240V 50-60Hz | Rate power : <= 45 VA Dimension 200*168*165mm,(L*W*H)   Pachymeter Probe frequency 20 Mhz Resolution 1µm Measurement range 0.23~1.3mm Accuracy ±5µm Power Requirement AC 100-240V 50-60Hz| Rate power: <= 45 VA Dimension 200*168*165 mm, (L*W*H)
