A-Scan Ultra Scanner

Scan Modes A Scan Application Hospital Brand Matronix IOL Formula Hoffer Q, SRK 2, SRK T Accuracy -+0.1 mm Dimension 200*168*165(mm,L*W*H) power 45 VA Examination modes Normal,Aphakic,pseudophakic and dense cataract Measurement mode immersion and contact,auto and Gain Adjustbale 0-120 db IOL formulas SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS Light Red-Light A-Scan probe 10MHz Measurement range 0.23-1.20 mm Measurements ACD,Lens,Vitreous and AXL Measurements Range 15-35 mm (vel 1640 m/s) Power requirement AC 100-240V 50-60 Hz Rate power - 45 VA Probe Frequency 10 MHz Probe frequency Pachy Meter 20 Mhz Resolution 0.01 mm   Show actual value and deviation at the same timeSensitive, convenient, accurate and fast measurementThe Probe service life is long, better cost performance Point and surface point measurementCabinet and delicate foot switch, convenient operationCalculate the calibration value of intraocular pressure (after achieving accurate intraocularpressure)Ultrasonic velocity and offset is adjustable compare measuring results with other equipmenteasily.5.7’ color LCD touch screen, and user information can be easily input, more convenient andquick.A-Scan Bio meter measurement integration of AL measurement and IOL calculation . reading average and standard deviation improve reading accuracy and liability 4 automatic measuring mode: normal. Cataract ,aphakic and special. IOL Calculation:- SRK-II, SRK-T, BINKHORST, HOLLADAY, HOFFER-Q, HAIGIS, any of two groups can control display. Calculate IOL,DEM,DAM, REEF, etc. And long term save 100 groups of measurement results of A scan.Specifications AddedEdit Accuracy: -+0.1 mm Application: Hospital Brand: Matronix Dimension: 200*168*165(mm,L*W*H) Examination modes: Normal, Aphakic, pseudophakic and dense cataract Measurement mode immersion and contact , auto and Gain Adjustable: 0-120 dB Gain Adjustbale: 0-120 db IOL formulas: SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS Light: Red-Light A-Scan probe 10MHz Measurement range: 0.23-1.20 mm Measurements: ACD,Lens,Vitreous and AXL Measurements Range: 15-35 mm (vel 1640 m/s) Power requirement: AC 100-240V 50-60 Hz Rate power - 45 VA Probe Frequency: 10 MHz Probe frequency Pachy Meter: 20 Mhz Resolution: 0.01 mm power: 45 VA
